Controller IC Chip - System Power PWM MOSFET APW8822 8822 APW8822A APW8822B APW8822C chip for laptop - Integrated Laptop Chip (Code 1-CHIP0310)

Controller IC Chip - System Power PWM MOSFET APW8822 8822 APW8822A APW8822B APW8822C chip for laptop - Integrated Laptop Chip (Code 1-CHIP0310)
Controller IC Chip - System Power PWM MOSFET APW8822 8822 APW8822A APW8822B APW8822C chip for laptop - Integrated Laptop Chip (Code 1-CHIP0310)
0 reviews • Write a review
from
9.90€
Ex Tax: 7.98€
  • Stock: In Stock
  • Brand: Unbranded
  • Model: 1-CHIP0310
  • SKU: 1-CHIP0310
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Realtime Stock

We send via DHL, UPS, USPS, FEDEX, Hellenic Greek Post, during the same day of the order placement. (Weekends are excluded).The average time of delivery for the United States is 13 to 18 days while for Europe is 5 to 7 days. Return Policy.

Our products are new and are shipped immediately. They have a 2 year warranty (except for batteries) and free shipping. Service line +302109247000 09:00-19:00 Mon-Fri. Our prices are without hidden charges and fees. We comply with the consumer rights directive 2011/83/EU. Any reference to the trademarks of the laptop manufacturers Toshiba, Lenovo, Acer, MSI, Asus, HP etc. is intended solely for the purpose of identifying the laptop manufacturer. Our Company and this website are not affiliated distributors with these manufacturers, the products offered for sale through our website are manufactured as high quality replacements by third party manufacturers. The products provided by our Company are not authentic. But they are worthy replacements and are sold for use in laptops of all manufacturers Toshiba Lenovo Acer MSI Asus HP etc.

Controller IC Chip - System Power PWM MOSFET APW8822 8822 APW8822A APW8822B APW8822C chip for laptop- Integrated portable calculator chip(SKU.1-CHIP0310)

The APW8822/A/B/C integrates dual step-down, constant-on-time, synchronous PWM controllers (that drives dual N-channel MOSFETs for each channel) and two low drop-out regulators as well as various protections into a chip. The PWM controllers step down high voltage of a battery to generate low-voltage for NB applications. The output of PWM1 and PWM2 can be adjusted from 2V to 5.5V by setting a resistive voltage-divider from VOUTx to GND. The linear regulators provide 5V and 3.3V output for standby power supply. The linear regulators provide up to 100mA output current. When the PWMx output voltage is higher than LDOx bypass threshold, the related LDOx regulator is shut off and its output is connected to VOUTx by internal switchover MOSFET. It can save power dissipation. The charge pump circuit with 270kHz clock driver uses VOUT1 as its power supply to generate ap-proximately 15V DC voltage. The APW8822/A/B/C provides excellent transient response and accurate DC output voltage in either PFM or PWM Mode. In Pulse-Frequency Mode (PFM), the APW8822/A/B/C provides very high efficiency over light to heavy loads with loading-modulated switching frequencies. The Forced-PWM Mode works nearly at constant frequency for low-noise requirements. The unique ultrasonic mode maintains the switching frequency above 25kHz, which eliminates noise in audio application.

Wide Input voltage Range from 6V to 25V Provide 5 Independent Outputs with ±1.0% Accu-racy Over-Temperature - PWM1 Controller with Adjustable (2V to 5.5V) Out-put - PWM2 Controller with Adjustable (2V to 5.5V) Out-put - 100mA Low Dropout Regulator (LDO5) with Fixed 5V Output - 100mA Low Dropout Regulator (LDO3) with Fixed 3.3V Output - 270kHz Clock Signal for 15V Charge Pump (Used VOUT1 as Its Power Supply) Excellent Line/Load Regulations about ±1.5% Over-Temperature Range Built in POR Control Scheme Implemented Constant On-Time Control Scheme with Frequency Compensation for PWM Mode Selectable Switching Frequency in PWM Mode Built-in Digital Soft-Start for PWM Outputs and Soft-Stop for PWM Outputs and LDO Outputs Integrated Bootstrap Forward P-CH MOSFET High Efficiency over Light to Full Load Range (PWMs) Built-in Power Good Indicators (PWMs) Independent Enable Inputs (PWMs, LDO) 70% Under-Voltage and 125% Over-Voltage Protec-tions (PWM) Adjustable Current-Limit Protection (PWMs) - Using Sense Low-Side MOSFET's R„,„, Over-Temperature Protection 3mmx3mm Thin QFN-20 (TQFN3x3-20) package Lead Free and Green Device Available (RoHS Compliant)
