Controller IC Chip - Standalone 1-Cell 1.5-A Linear Battery Charger MOFSET BQ24072RGTR BQ24072 chip for laptop - Integrated Laptop Chip (Ref.1-CHIP0333)

Controller IC Chip - Standalone 1-Cell 1.5-A Linear Battery Charger MOFSET BQ24072RGTR BQ24072 chip for laptop- Integrated portable calculator chip(SKU.1-CHIP0333)

The B02407x series of devices are integrated Li-Ion linear chargers and system power path management devices targeted at space-limited portable applications. The devices operate from either a USB port or an AC adapter and support charge currents up to 1.5 A. The input voltage range with input overvoltage protection supports unregulated adapters. The USB input current limit accuracy and start up sequence allow the B02407x to meet USB-IF inrush current specifications. Additionally, the input dynamic power management (VIN-DPM) prevents the charger from crashing incorrectly configured USB sources.
The 602407x features dynamic power path management (DPPM) that powers the system while simultaneously and independently charging the battery. The DPPM circuit reduces the charge current when the input current limit causes the system output to fall to the DPPM threshold; thus, supplying the system load at all times while monitoring the charge current separately. This feature reduces the number of charge and discharge cycles on the battery, allows for proper charge termination and enables the system to run with a defective or absent battery pack.

Fully compliant USB charger — Selectable 100-mA and 500-mA maximum input current — 100-mA Maximum current limit ensures compliance to USB-IF standard — Input-based dynamic power management WIN" DPM) for protection against poor USB sources 28-V Input Rating with Overvoltage Protection Integrated dynamic power path management (DPPM) function simultaneously and independently powers the system and charges the battery Supports up to 1.5-A charge current with current monitoring output (ISET) Programmable input current limit up to 1.5 A for wall adapters System output tracks battery voltage (bq24072) Programmable termination current (bq24074) Battery disconnect function with SYSOFF input (bq24075, bq24079) Programmable Pre-charge and Fast-charge safety timers Reverse current, short-circuit and thermal protection NTC thermistor input Proprietary start-up sequence limits inrush current Status indication — Charging/done, power good

Please check the model number in our description as well as our photo..

Please check the IC Number and match with your existing Product.

When you receive before using it.

Please confirm the chip you received is brand new as described,if you suspect the chip is not new or not as described. Please don't use it and contact us immediately.

Please make sure you have advanced soldering skill to solder the chips that you will order.

Once it has been used, no return will be accepted.
