Controller IC Chip - SC452IM SC452IMLTR SC 452 5C452 SC4S2 SC45Z SC452 SC452IMLTRT QFN 44 Chip for laptop - Integrated Laptop Chip (Code 1-CHIP1014)

Controller IC Chip - SC452IM SC452IMLTR SC 452 5C452 SC4S2 SC45Z SC452 SC452IMLTRT QFN 44 Chip for laptop- Integrated portable calculator chip(SKU.1-CHIP1014)

The SC452 is a single chip high-performance PWM controller designed to power advanced IMVP-6™ processors. On-chip support is provided for all of the IMVP-6 requirements, including Active Voltage Positioning, Geyserville-3 VID transitions, VID-controlled Deeper Sleep voltage setting, PSI# and DPRSL control, fast/slow C4 exit, and default Boot voltage. The SC452 implements hysteretic control technology which provides the fastest possible transient response while avoiding the stability issues inherent to classical PWM controllers. Semtech’s proprietary Combi-Sense® technology provides a loss-less current sensing scheme which is extremely robust and easy to lay out. Eliminating the sense resistors reduces costs and PCB area, plus increases system effi ciency. Integrated SmartDriver™ technology initially turns on the high side driver with ‘soft’ drive to reduce ringing, EMI, and capacitive turn-on of the low side MOSFET, while also increasing overall effi ciency. Hysteretic operation adaptively reduces the SC452 switching frequency at light loads. Combined with an automatic “power-save” mode which prevents negative current fl ow in the low-side FET, system effi ciency is signifi cantly enhanced during light loading conditions. The SC452 changes from dual-phase to single-phase operation whenever PSI# asserts, providing optimal effi ciency across the entire power range. A 7-bit DAC, accurate to 0.85%, sets the output voltage reference, and implements the 0.300V to 1.500V range required by the processor. The DAC slew rate is externally programmed to minimize transient currents and audible noise. True differential remote sensing provides accurate point-of-load regulation at the processor die. Other features include programmable soft-start, open-drain IMVP6_PWRGD and CLKEN# outputs, dynamic current sharing, over-voltage and programmable over-current protection. The SC452 is available in a space-saving 44 pin MLP package.

Dual-Phase Solution with Integrated Drivers ‹ Hysteretic Control for Fast Transient Response ‹ Combi-Sense Provides Loss-Less Current Sensing ‹ Dynamic Current Sharing ‹ Active Voltage Positioning ‹ True Differential Remote (die) Sensing ‹ On-Chip Support for all IMVP-6 Power Management Features ‹ VID Programmed Deeper Sleep Voltage ‹ Fast/Slow C4E Break-Event Support ‹ Clock Enable (CLKEN#) Output ‹ Delayed Power Good Signal with Blanking ‹ Programmable Soft-Start and DAC Slew Control ‹ Programmable OCP Threshold ‹ Supports all Ceramic Decoupling Solutions ‹ 44 pin MLP (7x7) ‹ Lead-free Package

Please check before you buy it

Please check the IC Number and match with your existing Product.

When you receive before using it, please confirm the chip you received is brand new as described,if you suspect the chip is not new or not as described.

Please don't use it and contact us immediately.

Please make sure you have advanced soldering skill to solder the chips that you will order.

Once it has been used, no return will be accepted.
