Controller IC Chip - High-Performance Notebook PWM Controller MOSFET APW7138 APW 7138 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0299)

Controller IC Chip - High-Performance Notebook PWM Controller MOSFET APW7138 APW 7138 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0299)
Controller IC Chip - High-Performance Notebook PWM Controller MOSFET APW7138 APW 7138 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0299)
0 reviews • Write a review
from
9.90€
Ex Tax: 7.98€
  • Stock: In Stock
  • Brand: Unbranded
  • Model: 1-CHIP0299
  • SKU: 1-CHIP0299
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Realtime Stock

We send via DHL, UPS, USPS, FEDEX, Hellenic Greek Post, during the same day of the order placement. (Weekends are excluded).The average time of delivery for the United States is 13 to 18 days while for Europe is 5 to 7 days. Return Policy.

Our products are new and are shipped immediately. They have a 2 year warranty (except for batteries) and free shipping. Service line +302109247000 09:00-19:00 Mon-Fri. Our prices are without hidden charges and fees. We comply with the consumer rights directive 2011/83/EU. Any reference to the trademarks of the laptop manufacturers Toshiba, Lenovo, Acer, MSI, Asus, HP etc. is intended solely for the purpose of identifying the laptop manufacturer. Our Company and this website are not affiliated distributors with these manufacturers, the products offered for sale through our website are manufactured as high quality replacements by third party manufacturers. The products provided by our Company are not authentic. But they are worthy replacements and are sold for use in laptops of all manufacturers Toshiba Lenovo Acer MSI Asus HP etc.

Controller IC Chip - High-Performance Notebook PWM Controller MOSFET APW7138 APW 7138 chip for laptop- Integrated portable calculator chip(SKU.1-CHIP0299)

The APW7138 is a single-phase, constant-on-time, and synchronous PWM controller which drives N-channel MOSFETs. The APW7138 steps down high voltage of a battery to generate low-voltage chipset or RAM supplies in notebook computers. The APW7138 provides excellent transient response and accurate DC voltage output in either PFM or PWM Mode. In Pulse Frequency Modulation (PFM) Mode, the APW7138 provides very high efficiency over light load with loading-modulated switching frequencies. When the inductor current is continuous, the operation automatically enters PWM mode with relatively constant switching frequency. For QFN4x4-16A and TQFN3x3-16 packages, the Forced-PWM Mode works nearly at constant frequency for low-noise requirements. The APW7138 is equipped with accurate over-current, output under-voltage, and over-voltage protections per-fect for NB application. A Power-On-Reset function moni-tors the voltage on VCC pin to prevent errorneous opera-tion during power-on. The APW7138 has a digital soft-start and soft-stop. The internal integrated soft-start ramps up the output voltage with controlled slew rate to reduce the start-up current. The digital soft-stop function actively discharges the output capacitors with controlled reverse inductor current. The APW7138 is available in SSOP-16, QFN4x4-16A, and TQFN3x3-16 packages.

Adjustable Output Voltage from +0.6V to +3.3V - 0.6V Reference Voltage - °/0 Accuracy Over Temperature Operates from an Input Battery Voltage Range of +3V to +25V Wide Output Load Range from OA to 25A Power-On-Reset Monitoring on VCC Pin Excellent Line and Load Transient Response PFM Mode for Increased Light Load Efficiency Programmable PWM Frequency from 200kHz to 600kHz Integrated MOSFET Drivers and Bootstrap Diode Internal Integrated Soft-Start and Soft-Stop Selectable Forced PWM or Automatic PFM/PWM Mode (only for QFN4x4-16A and TQFN3x3-16 Packages) Power Good Monitoring Fault Identification by PGOOD Pull-Down Resistance 70% Under-Voltage Protection (UVP) 124% Over-Voltage Protection (OVP) Adjustable Over-Current Protection (OCP) - Sensing Low-Side MOSFET's Current Over-Temperature Protection (OTP) SSOP-16. Compact 4mmx4mm QFN-16 (QFN4x4- 16A). and TQFN3x3-16 Packages Lead Free and Green Devices Available (RoHS Compliant)

Please check the model number in our description as well as our photo..

Please check the IC Number and match with your existing Product.

When you receive before using it.

Please confirm the chip you received is brand new as described,if you suspect the chip is not new or not as described. Please don't use it and contact us immediately.

Please make sure you have advanced soldering skill to solder the chips that you will order.

Once it has been used, no return will be accepted.
