Controller IC Chip - Dual N-Channel MOSFET FDMC7200 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0421)

Controller IC Chip - Dual N-Channel MOSFET FDMC7200 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0421)
Controller IC Chip - Dual N-Channel MOSFET FDMC7200 chip for laptop - Integrated Laptop Chip (Code 1-CHIP0421)
0 reviews • Write a review
from
9.90€
Ex Tax: 7.98€
  • Stock: In Stock
  • Brand: Unbranded
  • Model: 1-CHIP0421
  • SKU: 1-CHIP0421
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Realtime Stock

We send via DHL, UPS, USPS, FEDEX, Hellenic Greek Post, during the same day of the order placement. (Weekends are excluded).The average time of delivery for the United States is 13 to 18 days while for Europe is 5 to 7 days. Return Policy.

Our products are new and are shipped immediately. They have a 2 year warranty (except for batteries) and free shipping. Service line +302109247000 09:00-19:00 Mon-Fri. Our prices are without hidden charges and fees. We comply with the consumer rights directive 2011/83/EU. Any reference to the trademarks of the laptop manufacturers Toshiba, Lenovo, Acer, MSI, Asus, HP etc. is intended solely for the purpose of identifying the laptop manufacturer. Our Company and this website are not affiliated distributors with these manufacturers, the products offered for sale through our website are manufactured as high quality replacements by third party manufacturers. The products provided by our Company are not authentic. But they are worthy replacements and are sold for use in laptops of all manufacturers Toshiba Lenovo Acer MSI Asus HP etc.

Controller IC Chip - Dual N-Channel MOSFET FDMC7200 chip for laptop- Integrated portable calculator chip(SKU.1-CHIP0421)

Dual N-Channel PowerTrench® MOSFET 30 V, 12 mΩ and 23.5 mΩ

This device includes two specialized N-Channel MOSFETs in a dual Power33 (3mm x 3mm MLP) package. The switch node has been internally connected to enable easy placement and routing of synchronous buck converters. The control MOSFET (Q1) and synchronous MOSFET (Q2) have been designed to provide optimal power efficiency.

Q1: N-Channel „ Max rDS(on) = 23.5 mΩ at VGS = 10 V, ID = 6 A „ Max rDS(on) = 38 mΩ at VGS = 4.5 V, ID = 5 A Q2: N-Channel „ Max rDS(on) = 12 mΩ at VGS = 10 V, ID = 8 A „ Max rDS(on) = 18 mΩ at VGS = 4.5 V, ID = 7 A „ RoHS Compliant

Please check the IC Number and match with your existing Product.

When you receive before using it.

Please confirm the chip you received is brand new as described,if you suspect the chip is not new or not as described. Please don't use it and contact us immediately.

Please make sure you have advanced soldering skill to solder the chips that you will order.

Once it has been used, no return will be accepted.
